Pu Strip Aperture 1.2 - 76.2mm Self Cleaning Screen Mesh For Quarry Industrial

  • 1
  • 2

Brand Name : Self Cleaning Wire Mesh Screens

Model Number : PU SCS

Certification : ISO9001 SGS

Place of Origin : China

MOQ : 10 Square Meter

Price : 3000USD- 10000USD/TON

Payment Terms : L/C, T/T, D/P, O/A Western Union, MoneyGram

Supply Ability : 8000SM/Week

Delivery Time : Within10-15days

Packaging Details : On Wooden Carton or Pallet

Wire Material : 65Mn High Carbon Steel Wire and SS304 Steel Wire

Wire Diameter : 1.00-12.7mm

Tensile Strength : 1700-1800Mpa

Aperture : 1.2-76.20mm

Strip Material : High Quality Polyurethane

Feature : Anti-Clogging,Self Cleaning

Screen Mesh Width : 500-2500mm

Wire Tolerance : <3%

Aperture Tolerance : <3%

Porduction Type : Can Do OEM

Products Name : Self Cleaning Screen Mesh

Aperture Type : V D H and S Type

MOQ : 5pcs

Application : Qarry, Coal,Mining Industrial

Contact Now

The Poly Self Cleaning Wire Mesh Screens from Mamba Screen Mesh MFG Company

Poly Self Cleaning Wire Mesh Screens Panels are designed for high abrasion applications where the material has a tendency to blind or peg. Produced using abrasion resistant polyurethane profiles molded over straight and crimped high quality steel wires, Poly Ripple Wire Mesh Screen could provide superior wear life.

Poly Self Cleaning Wire Mesh Screens are high production wire screens developed to enhance cleaning and non-blinding action, using independently vibrating weft wires. There are various designs that provide screening accuracy close to traditional wire mesh in square, triangle or slotted openings. These screens significantly reduce blinding and pegging in severe applications.

Poly Self Cleaning Wire Mesh Screens could be custom-fabricated to meet customer requirements, no deck modification is required.MamBa Screen Mesh MFG Company’s Self Cleaning Wire Mesh Screens usually come with these designs: Diamond Opening, Triangle Opening, Waving Opening and Harp Type.

Incircle Opening size:
1.2 - 76.2mm
Steel Wire diameter:
1 - 12.7mm

Regular PU Strip Sizes:

Thickness:2.5mm-3mm, Width:2mm-5mm, Max Length:2.5m

Refer The following Picture.

Pu Strip Aperture 1.2 - 76.2mm Self Cleaning Screen Mesh For Quarry Industrial

PU Strip Self Cleaning Screen Material:

Main Material highly abrasion-resistant spring steel wire or stainless spring steel wire.

No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60


No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26

PU Strip Self Cleaning Screen Characteristics:


1. high performance production
2. More opening area
3. 30% more capacity than woven wire
4. Eliminates blinding and plugging
5. 3 times longer wear life time than woven wire
6. Minimizes down time cleaning and unclogging
7. Maximizes throughput


Pu Strip Self Cleaning Screen Hook Types:

Our hook making adopts the electromagnetic coil heating process. All hooks are one-time forming. There are different type of hooks and edges available.
We can provide wire cloth with or without hooks and wire cloth rolls in different size according to client’s requests.

Pu Strip Self Cleaning Screen Characteristic

Our self cleaning screens are available in high tensile steel mesh or stainless steel. Also with or without polyurethane cross strips. Self cleaning screens are a non-blinding, high quality screening surface that provides accurate screening and sizing. Particularly where material is difficult, wet or sticky. In addition to having many advantages over other screen types, self cleaning mesh gives higher production rates. At the same time eliminating the problem of large unwanted flat material that contaminates the finished product.

THE BENEFITS OF SELF CLEANING SCREENS:

  • Anti-clogging
  • Increased wear life
  • Accurate sizing
  • Anti-pegging
  • Available to suit all types of mobile and static screens

With high quality, non-blinding screening is the perfect mesh. The combination of different size wire used in manufacture means that they vibrate at varying frequencies to produce a self-cleaning surface. Also, due to its flat surface (no knuckles) self cleaning screens can use a smaller wire diameter than woven wire for some applications. Therefore it has a greater opening area percentage and still lasts as long as normal square woven mesh.


Pu Strip Aperture 1.2 - 76.2mm Self Cleaning Screen Mesh For Quarry Industrial

Application:
applies to vibrating screens for primary sieving of mine and aggregates, as well as asphalt mixer plant in road building.

Pu Strip Aperture 1.2 - 76.2mm Self Cleaning Screen Mesh For Quarry Industrial
